2 P ush "E" key at least for 3 s
3 D
oes the LED on the electronics module light briefly?
Y es: existing pressure was accepted as position adjustment
N o: Existing pressure for position adjustment was not accepted,
note the adjustment limits
Adjust max. pressure value:
1 R equested pressure for max. pressure value (MAX. PRESSURE
FLOW) is on the instrument
2 P ush "+" key at least for 3 s
3 D oes the LED on the electronics module light briefly?
Y es: Existing pressure was saved as max. pressure value (MAX.
PRESSURE FLOW) and assigned to the max. flow value (MAX.
FLOW).
N o. Existing pressure for measurement begin was not saved as
max. pressure value. Note the adjustment limits
6 .5 Local adjustment - local indication connected
I f the local indication is connected, the three adjustment key are used
for navigation in the adjustment menu, see chapter "Function of the
operating elements".
T he menu is divided into four levels. The three upper levels are used
for navigation whereas on the lowest level, numerical values are
entered, options selected and saved. The complete menu is shown in
chapter "Menu schematic". The "Adjustment menu" is composed
according to the selected mode, e.g. when the mode "Pressure" is
selected, only the functions necessary for this mode are displayed.
T he parameters LANGUAGE and MODE are shown via the local
indication on the 1. selection level. Via the digital communication, the
parameter LANGUAGE is shown in group INDICATION and the
parameter MODE in the function group BASIC ADJUSTMENT.
Configuration of the
menu
