Supplement b – VEGA VEGACOM 558 Ethernet User Manual
Page 73
VEGACOM 558 Ethernet
73
Supplement B
Register w ord
address
in
Modicon
Module no.
No. of output
DISBUS address
Status /
Sw itching status
10.225
#15
Output contact 9
VEGAMET #15
Input contact 2
10.226
#15
Output contact 10
VEGAMET #15
Input contact 1
10.227
#15
-
VEGAMET #15
-
10.228
#15
-
VEGAMET #15
-
10.229
#15
-
VEGAMET #15
-
10.230
#15
-
VEGAMET #15
-
10.231
#15
-
VEGAMET #15
-
10.232
#15
Status: Card
VEGAMET #15
Status of inputs
10.233
#15
Output contact 1
VEGAMET #15
Relay contact 1
10.234
#15
Output contact 2
VEGAMET #15
Relay contact 2
10.235
#15
Output contact 3
VEGAMET #15
Fail safe relay
10.236
#15
Output contact 4
VEGAMET #15
-
10.237
#15
Output contact 5
VEGAMET #15
-
10.238
#15
Output contact 6
VEGAMET #15
-
10.239
#15
Output contact 7
VEGAMET #15
-
10.240
#15
Output contact 8
VEGAMET #15
Status of outputs
10.241
#16
Output contact 9
-
-
10.242
#16
Output contact 10
-
-
10.243
#16
-
-
-
10.244
#16
-
-
-
10.245
#16
-
-
-
10.246
#16
-
-
-
10.247
#16
-
-
-
10.248
#16
Status: Card
-
-
10.249
#16
Output contact 1
-
-
10.250
#16
Output contact 2
-
-
10.251
#16
Output contact 3
-
-
10.252
#16
Output contact 4
-
-
10.253
#16
Output contact 5
-
-
10.254
#16
Output contact 6
-
-
10.255
#16
Output contact 7
-
-
10.256
#16
Output contact 8
-
-
10.257
#17
Output contact 9
-
-
10.258
#17
Output contact 10
-
-
10.259
#17
-
-
-
10.260
#17
-
-
-
10.261
#17
-
-
-
10.262
#17
-
-
-
10.263
#17
-
-
-
10.264
#17
Status: Card
-
-
10.265
#17
Output contact 1
-
-
10.266
#17
Output contact 2
-
-
10.267
#17
Output contact 3
-
-
10.268
#17
Output contact 4
-
-
10.269
#17
Output contact 5
-
-
VEGALOG
VEGAMET
513, 514, 515, 614
