VEGACOM 558 Ethernet 29
30001
30003
30005
30007
30009
30011
30013
30015
30505
30507
30509
30017
4 Byte
Register
address
in
Modicon
DCS output 2
DCS output 1
DCS output 3
DCS output 4
DCS output 5
DCS output 6
DCS output 7
DCS output 8
DCS output 9
DCS output 253
DCS output 254
DCS output 255
High-
Byte
Low-
Byte
Meas.
unit
Sta-
tus
Meas.
value Add. info
Addressing of the measured value when connected to
LOGBUS
Data image in VEGACOM 558
Addressing of measured values when
connected to LOGBUS
The measured value image when connected
to LOGBUS is always sorted acc. to the DCS
outputs, the following illustration shows the
addressing of the temporary memory via
Modbus.
Note:
A complete overview of the process image of
the measured values of VEGACOM 558 can
be found in supplement A at the end of this
operating instructions manual.
Temporary memory of
VEGACOM 558
