VEGA VEGACOM 558 Ethernet - Manual (Page 63)

VEGACOM 558 Ethernet 63
Register word
address
VEGALOG Sorting acc. to
VEGAMET addresses
Sorting acc. to
channels / DCS indices
in
Modicon
VEGAMET 513
514, 515, 614
VEGAMET 513
514, 515, 614
30.089 DCS 45 MET6 DCS3 DCS3 MET12
30.091 DCS 46 MET6 DCS4 DCS3 MET13
30.093 DCS 47 MET6 DCS5 DCS3 MET14
30.095 DCS 48 MET6 DCS6 DCS3 MET15
30.097 DCS 49 MET6 DCS7 -
30.099 DCS 50 MET7 DCS1 DCS4 MET1
30.101 DCS 51 MET7 DCS2 DCS4 MET2
30.103 DCS 52 MET7 DCS3 DCS4 MET3
30.105 DCS 53 MET7 DCS4 DCS4 MET4
30.107 DCS 54 MET7 DCS5 DCS4 MET5
30.109 DCS 55 MET7 DCS6 DCS4 MET6
30.111 DCS 56 MET7 DCS7 DCS4 MET7
30.113 DCS 57 MET8 DCS1 DCS4 MET8
30.115 DCS 58 MET8 DCS2 DCS4 MET9
30.117 DCS 59 MET8 DCS3 DCS4 MET10
30.119 DCS 60 MET8 DCS4 DCS4 MET11
30.121 DCS 61 MET8 DCS5 DCS4 MET12
30.123 DCS 62 MET8 DCS6 DCS4 MET13
30.125 DCS 63 MET8 DCS7 DCS4 MET14
30.127 DCS 64 MET9 DCS1 DCS4 MET15
30.129 DCS 65 MET9 DCS2 -
30.131 DCS 66 MET9 DCS3 DCS5 MET1
30.133 DCS 67 MET9 DCS4 DCS5 MET2
30.135 DCS 68 MET9 DCS5 DCS5 MET3
30.137 DCS 69 MET9 DCS6 DCS5 MET4
30.139 DCS 70 MET9 DCS7 DCS5 MET5
30.141 DCS 71 MET10 DCS1 DCS5 MET6
30.143 DCS 72 MET10 DCS2 DCS5 MET7
30.145 DCS 73 MET10 DCS3 DCS5 MET8
30.147 DCS 74 MET10 DCS4 DCS5 MET9
30.149 DCS 75 MET10 DCS5 DCS5 MET10
30.151 DCS 76 MET10 DCS6 DCS5 MET11
30.153 DCS 77 MET10 DCS7 DCS5 MET12
30.155 DCS 78 MET11 DCS1 DCS5 MET13
30.157 DCS 79 MET11 DCS2 DCS5 MET14
30.159 DCS 80 MET11 DCS3 DCS5 MET15
30.161 DCS 81 MET11 DCS4 -
30.163 DCS 82 MET11 DCS5 DCS6 MET1
30.165 DCS 83 MET11 DCS6 DCS6 MET2
30.167 DCS 84 MET11 DCS7 DCS6 MET3
30.169 DCS 85 MET12 DCS1 DCS6 MET4
30.171 DCS 86 MET12 DCS2 DCS6 MET5
30.173 DCS 87 MET12 DCS3 DCS6 MET6
30.175 DCS 88 MET12 DCS4 DCS6 MET7
30.177 DCS 89 MET12 DCS5 DCS6 MET8
Supplement A
