VEGACOM 558 Ethernet
Contents
Safety information
Please read this manual carefully, and also take
note of country-specific installation standards
(e.g. the VDE regulations in Germany) as well
as all prevailing safety regulations and acci-
dent prevention rules.
For safety and warranty reasons, any internal
work on the instruments, apart from that in-
volved in normal installation and electrical con-
nection, must be carried out only by qualified
VEGA personnel.
Note Ex area
Please note the attached safety instructions
containing important information on installation
and operation in Ex areas.
These safety instructions are part of the oper-
ating instructions and come with the Ex ap-
proved instruments.
Contents
Safety information ........................................................................ 2
Note Ex area ................................................................................ 2
1
Product description
1.1 Function ................................................................................. 4
1.2 Configuration ........................................................................ 4
1.3 Technical data ....................................................................... 5
1.4 Dimensions ........................................................................... 7
2
Mounting ..................................................................................... 8
3
Electrical connection
3.1 Connection instruction ......................................................... 9
3.2 Wiring plan ............................................................................ 9
4
Communication with VEGACOM
4.1 Ways to connect ................................................................ 10
4.2 Adjustment software .......................................................... 11
5
Configuration of VEGACOM 558
5.1 Adjust communication mode with VVO ............................ 15
5.2 IP address .......................................................................... 16
5.3 Connection via modem ...................................................... 17
5.4 VEGACOM 558 on DISBUS .............................................. 19
5.5 Real time clock ................................................................... 20
5.6 Activate password protection ........................................... 21
