VEGACOM 557 Modbus
59
Supplement B
Register w ord
address
Register w ord
address
in
Modicon
in
VEGACOM
Module no.
No. of output
DISBUS address
Status /
Sw itching status
10.135
134
#9
-
VEGAMET #9
-
10.136
135
#9
Status: Card
VEGAMET #9
Status of inputs
10.137
136
#9
Output contact 1
VEGAMET #9
Relay contact 1
10.138
137
#9
Output contact 2
VEGAMET #9
Relay contact 2
10.139
138
#9
Output contact 3
VEGAMET #9
Fail safe relay
10.140
139
#9
Output contact 4
VEGAMET #9
-
10.141
140
#9
Output contact 5
VEGAMET #9
-
10.142
141
#9
Output contact 6
VEGAMET #9
-
10.143
142
#9
Output contact 7
VEGAMET #9
-
10.144
143
#9
Output contact 8
VEGAMET #9
Status of outputs
10.145
144
#10
Output contact 9
VEGAMET #10
Input contact 2
10.146
145
#10
Output contact 10
VEGAMET #10
Input contact 1
10.147
146
#10
-
VEGAMET #10
-
10.148
147
#10
-
VEGAMET #10
-
10.149
148
#10
-
VEGAMET #10
-
10.150
149
#10
-
VEGAMET #10
-
10.151
150
#10
-
VEGAMET #10
-
10.152
151
#10
Status: Card
VEGAMET #10
Status of inputs
10.153
152
#10
Output contact 1
VEGAMET #10
Relay contact 1
10.154
153
#10
Output contact 2
VEGAMET #10
Relay contact 2
10.155
154
#10
Output contact 3
VEGAMET #10
Fail safe relay
10.156
155
#10
Output contact 4
VEGAMET #10
-
10.157
156
#10
Output contact 5
VEGAMET #10
-
10.158
157
#10
Output contact 6
VEGAMET #10
-
10.159
158
#10
Output contact 7
VEGAMET #10
-
10.160
159
#10
Output contact 8
VEGAMET #10
Status of outputs
10.161
160
#11
Output contact 9
VEGAMET #11
Input contact 2
10.162
161
#11
Output contact 10
VEGAMET #11
Input contact 1
10.163
162
#11
-
VEGAMET #11
-
10.164
163
#11
-
VEGAMET #11
-
10.165
164
#11
-
VEGAMET #11
-
10.166
165
#11
-
VEGAMET #11
-
10.167
166
#11
-
VEGAMET #11
-
10.168
167
#11
Status: Card
VEGAMET #11
Status of inputs
10.169
168
#11
Output contact 1
VEGAMET #11
Relay contact 1
10.170
169
#11
Output contact 2
VEGAMET #11
Relay contact 2
10.171
170
#11
Output contact 3
VEGAMET #11
Fail safe relay
10.172
171
#11
Output contact 4
VEGAMET #11
-
10.173
172
#11
Output contact 5
VEGAMET #11
-
10.174
173
#11
Output contact 6
VEGAMET #11
-
10.175
174
#11
Output contact 7
VEGAMET #11
-
10.176
175
#11
Output contact 8
VEGAMET #11
Status of outputs
10.177
176
#12
Output contact 9
VEGAMET #12
Input contact 2
10.178
177
#12
Output contact 10
VEGAMET #12
Input contact 1
10.179
178
#12
-
VEGAMET #12
-
VEGALOG
VEGAMET
513, 514, 515, 614
