VEGACOM 557 Modbus 19
Terminals
for supply voltage
Terminals
for DISBUS
View of back-panel board (rear of the carrier)
Front view with SUB-D-connections of VEGACOM 557
and VEGACOM 557AP
on
557
BA
PC
557AP
PC interface of
VEGACOM 557
Modbus interface
of VEGACOM 557
as SUB-D-plug
Modbus interface
of VEGACOM 557
as SUB-D-socket
Mounting and electrical connection
Ub+
