VEGA VEGACOM 557 Modbus protocol User Manual
Page 57
VEGACOM 557 Modbus
57
Supplement B
Register w ord
address
Register w ord
address
in
Modicon
in
VEGACOM
Module no.
No. of output
DISBUS address
Status /
Sw itching status
10.045
44
#3
Output contact 5
VEGAMET #3
-
10.046
45
#3
Output contact 6
VEGAMET #3
-
10.047
46
#3
Output contact 7
VEGAMET #3
-
10.048
47
#3
Output contact 8
VEGAMET #3
Status of outputs
10.049
48
#4
Output contact 9
VEGAMET #4
Input contact 2
10.050
49
#4
Output contact 10
VEGAMET #4
Input contact 1
10.051
50
#4
-
VEGAMET #4
-
10.052
51
#4
-
VEGAMET #4
-
10.053
52
#4
-
VEGAMET #4
-
10.054
53
#4
-
VEGAMET #4
-
10.055
54
#4
-
VEGAMET #4
-
10.056
55
#4
Status: Card
VEGAMET #4
Status of inputs
10.057
56
#4
Output contact 1
VEGAMET #4
Relay contact 1
10.058
57
#4
Output contact 2
VEGAMET #4
Relay contact 2
10.059
58
#4
Output contact 3
VEGAMET #4
Fail safe relay
10.060
59
#4
Output contact 4
VEGAMET #4
-
10.061
60
#4
Output contact 5
VEGAMET #4
-
10.062
61
#4
Output contact 6
VEGAMET #4
-
10.063
62
#4
Output contact 7
VEGAMET #4
-
10.064
63
#4
Output contact 8
VEGAMET #4
Status of outputs
10.065
64
#5
Output contact 9
VEGAMET #5
Input contact 2
10.066
65
#5
Output contact 10
VEGAMET #5
Input contact 1
10.067
66
#5
-
VEGAMET #5
-
10.068
67
#5
-
VEGAMET #5
-
10.069
68
#5
-
VEGAMET #5
-
10.070
69
#5
-
VEGAMET #5
-
10.071
70
#5
-
VEGAMET #5
-
10.072
71
#5
Status: Card
VEGAMET #5
Status of inputs
10.073
72
#5
Output contact 1
VEGAMET #5
Relay contact 1
10.074
73
#5
Output contact 2
VEGAMET #5
Relay contact 2
10.075
74
#5
Output contact 3
VEGAMET #5
Fail safe relay
10.076
75
#5
Output contact 4
VEGAMET #5
-
10.077
76
#5
Output contact 5
VEGAMET #5
-
10.078
77
#5
Output contact 6
VEGAMET #5
-
10.079
78
#5
Output contact 7
VEGAMET #5
-
10.080
79
#5
Output contact 8
VEGAMET #5
Status of outputs
10.081
80
#6
Output contact 9
VEGAMET #6
Input contact 2
10.082
81
#6
Output contact 10
VEGAMET #6
Input contact 1
10.083
82
#6
-
VEGAMET #6
-
10.084
83
#6
-
VEGAMET #6
-
10.085
84
#6
-
VEGAMET #6
-
10.086
85
#6
-
VEGAMET #6
-
10.087
86
#6
-
VEGAMET #6
-
10.088
87
#6
Status: Card
VEGAMET #6
Status of inputs
10.089
88
#6
Output contact 1
VEGAMET #6
Relay contact 1
VEGALOG
VEGAMET
513, 514, 515, 614
