VEGA VEGACOM 557 Modbus protocol User Manual
Page 58
58
VEGACOM 557 Modbus
Supplement B
Register w ord
address
Register w ord
address
in
Modicon
in
VEGACOM
Module no.
No. of output
DISBUS address
Status /
Sw itching status
10.090
89
#6
Output contact 2
VEGAMET #6
Relay contact 2
10.091
90
#6
Output contact 3
VEGAMET #6
Fail safe relay
10.092
91
#6
Output contact 4
VEGAMET #6
-
10.093
92
#6
Output contact 5
VEGAMET #6
-
10.094
93
#6
Output contact 6
VEGAMET #6
-
10.095
94
#6
Output contact 7
VEGAMET #6
-
10.096
95
#6
Output contact 8
VEGAMET #6
Status of outputs
10.097
96
#7
Output contact 9
VEGAMET #7
Input contact 2
10.098
97
#7
Output contact 10
VEGAMET #7
Input contact 1
10.099
98
#7
-
VEGAMET #7
-
10.100
99
#7
-
VEGAMET #7
-
10.101
100
#7
-
VEGAMET #7
-
10.102
101
#7
-
VEGAMET #7
-
10.103
102
#7
-
VEGAMET #7
-
10.104
103
#7
Status: Card
VEGAMET #7
Status of inputs
10.105
104
#7
Output contact 1
VEGAMET #7
Relay contact 1
10.106
105
#7
Output contact 2
VEGAMET #7
Relay contact 2
10.107
106
#7
Output contact 3
VEGAMET #7
Fail safe relay
10.108
107
#7
Output contact 4
VEGAMET #7
-
10.109
108
#7
Output contact 5
VEGAMET #7
-
10.110
109
#7
Output contact 6
VEGAMET #7
-
10.111
110
#7
Output contact 7
VEGAMET #7
-
10.112
111
#7
Output contact 8
VEGAMET #7
Status of outputs
10.113
112
#8
Output contact 9
VEGAMET #8
Input contact 2
10.114
113
#8
Output contact 10
VEGAMET #8
Input contact 1
10.115
114
#8
-
VEGAMET #8
-
10.116
115
#8
-
VEGAMET #8
-
10.117
116
#8
-
VEGAMET #8
-
10.118
117
#8
-
VEGAMET #8
-
10.119
118
#8
-
VEGAMET #8
-
10.120
119
#8
Status: Card
VEGAMET #8
Status of inputs
10.121
120
#8
Output contact 1
VEGAMET #8
Relay contact 1
10.122
121
#8
Output contact 2
VEGAMET #8
Relay contact 2
10.123
122
#8
Output contact 3
VEGAMET #8
Fail safe relay
10.124
123
#8
Output contact 4
VEGAMET #8
-
10.125
124
#8
Output contact 5
VEGAMET #8
-
10.126
125
#8
Output contact 6
VEGAMET #8
-
10.127
126
#8
Output contact 7
VEGAMET #8
-
10.128
127
#8
Output contact 8
VEGAMET #8
Status of outputs
10.129
128
#9
Output contact 9
VEGAMET #9
Input contact 2
10.130
129
#9
Output contact 10
VEGAMET #9
Input contact 1
10.131
130
#9
-
VEGAMET #9
-
10.132
131
#9
-
VEGAMET #9
-
10.133
132
#9
-
VEGAMET #9
-
10.134
133
#9
-
VEGAMET #9
-
VEGALOG
VEGAMET
513, 514, 515, 614
