18 SPARE PART LIST
Wear, tear and replacement part requirements depend on specific operating conditions.
The recommended quantities are based on experience and are not binding.
Portable Gas Conditioning Unit Version CSS-M
(V) Consumables, (E) Recommended Spare Parts and (T) Spare Parts
Recommended quantity after
operation of [years]
Part No.
Description V/E/T 1 2 3
Fine filter FPF-2-0,3GF
90 F 0160 Filter element type F-2-0,3GF. Material:
glass fiber, porosity: 0,3µ 25 pcs./pack. V 1 2 3
90 F 0167 O-ring FPF-2/54. Material: Viton. E 1 1 1
Peristaltic pump SR25.1:
90 P 1007 SR25 pump hose with threaded hose
coupling of PVDF, DN 4/6mm V 1 2 4
Diaphragm pump type N3 KPE
90P2100
Square cap type D3, 1/8“i for
N3/N5 KPE/KP18. Material: PVDF
T - - 1
90P2120 Diaphragm type S3, for
N3/N5 KPE/KP18,
Material: Viton, PTFE coated V 1 2 3
90P2115 O-ring type O3, for N3/N5 KPE/KP18,
1 pc., Material: Viton (2 pcs. Required) V 2 4 6
90P2110 Valve plate type V3, for N3/N5 KPE/KP18,
1 pc., Material: Viton (2 pcs. Required) V 2 4 6
90P2105 Intermediate plate type Z3, for
N3/N5 KPE/KP18, Material: PVDF T - - 1
Flow meter FM40:
90 A 0015 Flow meter glass for FM40
Measuring range 7-70 l/hr air T - 1 1
90 A 0018 Viton O-ring 9 for FM40 glass E 2 4 6
Miscellaneous:
90 K 6030 Fine fuse 4A T , 5x20mm for CSS... E 5 5 5
Hose and threaded hose couplings:
05 V 3215 Bulkhead union SV-PVDF DN 4/6 E 2 2 2
05 V 6600 Ferrule 4/6 PVDF s.a. E 5 10 10
05 V 6605 Union nut M10-4/6 PVDF s.a. E 5 10 10
01 T 1000 Viton tube NW 4/6 (m) T 1 2 3
10 T 1000 Hose cutter T 1 1 1
