21
Gas sampling and gas conditioning technology 3-1.10-ME
19 SPARE PARTS LIST
Wear, tear and replacement part requirements depend on specific operating conditions.
The recommended quantities are based on experience and are not binding.
Electric Gas Cooler ECP20-1, ECP20-2
(C) consumable parts, (R) recommended spare parts, (S) spare parts
recommended quantity
ECP... being in operation
[years]
C/R/S 1 2 3
02 K 9100 EC-G Jet-Stream Heat Exchanger
Material: Duran Glass
Connections: Gas GL18-6/6mm
Condensate : GL25-12mm
R 1 1 1
02 K 9150 EC-G Jet-Stream Heat Exchanger with 90°
angled gas connections
Material: Duran Glass
Connections: Gas GL18-6/6mm
Condensate: GL25-12mm
R 1 1 1
02 K 9200 EC-SS Jet-Stream Heat Exchanger
Material: SS 316
Connections: Gas G 1/4" i
Condensate: G 3/8" i
R 1 1 1
02 K 9300 EC-PV Jet-Stream Heat Exchanger
Material: PVDF
Connections: Gas G 1/4" i
Condensate: G 3/8" i
R 1 1 1
90 K 0115 Heat sink compound 50g Type 80B522 R 1 1 2
93 K 0020 ECP20 Electronic Board complete
from serial nos.: 95...
R - 1 1
90 K 6030 4A fine-wire fuse 5mm x 20mm (F1/2) R 2 4 4
90 K 0040 ECP Fan (M1/2 - 115V 60Hz) C - 2 2
90 K 0045 Internal cable for connection of fan, incl. plug R - - 1
90 K 2010 ECP20 Rectifier R - 1 1
90 K 2020 ECP20 Power Transistor BUZ11 R - 1 1
90 K 2030
ECP20-1 Toroidal core transformer
115/230 V, 120VA R - - 1
