25
Gas sampling and gas conditioning technology 3-4.1ME EC-EX 9904
22 SPARE PARTS LIST
Wear, tear and replacement part requirements depend on specific operating conditions.
The recommended quantities are based on experience and are not binding.
Electric gas cooler EC-EX
(C) consumable parts and (R) recommended spare parts
recommended quantity
EC-EX being in
operation [years]
Part number
Description C/R 1 2 3
02 K 9105 EC-G jet stream heat exchanger
material: Borosilicate glass R 1 1 1
02 K 9150 EC-G-90° jet stream heat exchanger
material: Borosilicate glass R 1 1 1
02 K 9200 EC-SS jet stream heat exchanger
material: stainless steel R 1 1 1
02 K 9250 EC-SS/NPT jet stream heat exchanger
material: stainless steel
Con
nections: sample gas in and out 1/4“i NPT
condensate out 3/8“i NPT
R 1 1 1
02 K 9300 EC-PV jet stream heat exchanger
material: PVDF R 1 1 1
90 K 0115 EC thermal conductivity paste 50 g (-40°C to
140°C) R 1 1 2
90 K 5010 EC-EX temperature sensor R51 E - - 1
90 K 5015 EC-EX Temperature contact S1 E - - 1
90 K 1010 EC-EX LED-display unit with connecting cable E - - 1
90 K 5035 EC-EX cooling unit complete with compressor
vaporizer and condenser. Supply 230V, 50Hz E - - -
90 K 5040 EC-EX cooling unit complete with compressor
vaporizer and condenser. Supply 115 V, 50-60 Hz E - - -
90 K 5021 EC-EX control board complete with EEx-d box,
230V/50Hz E - - -
