7

Gas sampling and gas conditioning technology

5-2.1.5-ME

6

INTRODUCTION

Hot sample gas very often contains solids like dust, taar or grime and water vapour. These materials
cause problems for a continuous gas analysis, especially when the gas temperature falls below the
dew point. The sample line will be blocked and the analyser will be damaged. Therefore the solids
have to be separated and a temperature drop below the dew point has to be prevented. For this
complex of problems the electrically heated M&C universal filter type FSS-../H350 was designed.


7

APPLICATION

The electrically heated M&C universal filter type FSS../H350 separates fine dust particles of 2 or 3 µm
or solids like taar or grime from the sample gas at operating temperatures up to 350 °C. For an
efficient filtration very fine filter elements with high deep action are used. For separation of e.g. taar
and grime a special filter cartridge filled up with spun glass is used.



8

TECHNICAL DATA

Heated filter type

FSS-2K/H350

FSS-3SS/H350

FSS-FW/H350

Version 115V AC

Part-No.

01F3035

01F3030

01F3045

01F30..-a

Filter element length 150 mm,
material

ceramic

stainless

steel

SS316

spun glass

Filter porosity

2

μm

3

μm

Filter surface

140 cm

2

Operating pressure max.

5 bar g

Ambient temperature / storage
temperature

-20 °C to +60 °C

Dead volume

130 cm

3

Gas connections

Swagelok tube connector ø6 mm, optional ø1/4"

Temperature controller

incorporated

capillary

sensor

thermostat,

with

temperature limiter switch and low temperature alarm
contact

Operating temperature

adjustable from +50 °C to 350 °C, set in factory 250 °C

Temperature alarm contact

alarm point at -30 °C below TSet change over contact,
voltage free, contact rating 250V, 3A ~ 0, 25A =

Power supply

230V 50Hz, 800VA

115V 60Hz

Electrical connections

Terminals 4 mm

2

, 2x cable glands PG13

Method of mounting

Wall mounting

Protection
classification/electrical
standard

IP 54 EN60529 / EN61010, EN60519-1

Dimensions / Weight

250 x 300 x 300 mm (w x h x d) / 11 kg

Material of sample contacting
parts

filter chamber: stainless steel 316Ti / sealing: graphite
