Example: 2SLSM 2PH + 2PLAY (2R/CM)
The BNC connectors to be used as record and play channels in an SLSM configuration
with 2SLSM 2PH + 2 PLAY in 2R/CM mode need to be cabled as shown below:
SLSM 3x Configurations
Available Configurations
IN4/OUT3 IN3/OUT4 IN2/OUT5 IN1/OUT6
#REC
SLSM
3x
#REC #PLAY
Prim.
Link Sec.
Link Prim.
Link Sec.
Link Prim.
Link Sec.
Link Prim.
Link Sec.
Link
1 0 1 PLAY1 REC1,
3 REC1,
2 REC1,
1
2R/CM Configuration
1 1 2 PLAY1 PLAY2 REC1,
2 REC2 REC1,
1 REC1,
3
XTnano Server - Version 11.01 - Configuration Manual
3. Multicam Configuration 62
