The following table shows the minimum and maximum number of channels that can be
operated in both modes:
XTnano
(V3X)
XTnano
(COHX)
SportLight Server SportLight Server
Max. #
channels 6 4 4 4
Min. #
REC 1 0 1 0
Max. #
REC 4 4 3 4
Min. #
PLAY 1 0 1 0
Max. #
PLAY 2 4 2 4
Note
Based on the above-mentioned limitations, some configurations described in the
following sections are only available in SportLight or Server mode.
Channel Assignment
The following general principles apply to all configurations, and are valid for all EVS
servers equipped with V3X or COHX boards:
• The record channels (IN connectors) are always assigned from the right to the left.
