Aspect ratio - SD downconverted
Description Changes the aspect ratio of the video output in SD mode.
Values • 16:9 Anamorphic
• 4:3 Crop
• 4:3 Letterbox
Default value 16:9 Anamorphic
HD output format
Description Specifies the format for HD output.
Values • 720p
• 1080i
Default value • 720p (if the EVS Server is configured in 720p)
• 1080i (in other cases)
3.6.3. OSD Settings
Introduction
The OSD settings allow specifying the settings related to the OSD and information to be
displayed on the monitoring screen.
These fields are available in the following interfaces:
• in the Multicam Configuration window, Monitoring tab.
• in the Technical menu of the Remote Control Panel (T4.1).
