Required Application Reboot
Modifications to some parameters will only be applied after an application reboot. This is
mentioned in the sections where the parameters are described. These parameters are
summarized below:
Tab Name Setting Name
Server tab Most video and reference settings:
• Field rate
• Resolution
• Codec
• Bitrate
• Horizontal res.
• LTC timecode
Server tab All PC LAN settings (only editable from the Multicam Setup window)
Channels tab Some base settings:
• Inputs
• Outputs
• Base config
Channels tab One audio setting:
• Number of tracks
Channels tab One recorder setting:
• Loop % (in IN1 XX% Loop field)
Network tab All Gigabit Ethernet settings:
• IP address
• Subnet mask
• Default gateway
Monitoring tab One setting in the Downconverted Outputs area:
• Aspect ratio
3.1.4. Overview of the Setup Menus in the Remote
Panel
Introduction
When you work in SportLight mode, the Technical and Operational Setup menus available
on the Remote Panel allow you to define:
• the commonly used technical settings in the Technical Setup menu
• all operational settings in the Operational Setup menu.
The values assigned to the settings are saved as soon as they are modified.
