3.2.4. SLSM Configurations
Introduction
SLSM Principles
This section details the available 2 phase and 3 phase SLSM configurations in SD/HD on
XTnano servers.
In SLSM 2 Phase configurations, one SLSM recorder accounts for one logical channel,
but corresponds to two physical channels.
In SLSM 3 Phase configurations, one SLSM recorder accounts for one logical channel,
but corresponds to three physical channels.
Overview on Configurations
The tables below show the available SLSM 2 Phase and SLSM 3 Phase configurations in
SD/HD with an XTnano server, and how the BNC connectors should be cabled.
The 2R/CM configurations, presented at the end of the tables, make use of the secondary
link of the codec module of a record channel as an independent recorder. See section
"Channel Assignment in 2R/CM Configurations" on page 56.
The option '2R/CM' is only available with an XTnano server equipped with V3X boards.
Note
Specific SLSM configurations for and 3D dual link configurations, only available
with V3X boards, are presented in the section "3D SLSM Configurations" on
page 66.
