YORK INTERNATIONAL 50
Component Static Pressure Drops
TABLE 23 – COMPONENT STATIC PRESSURE DROPS (PASCALS OF
WATER COLUMN)
2-POSITION OR VFD
MODULATING EXHAUST
SIZE
AIR FLOW
POWERED EXHAUST
(CONTROL DAMPER) m3/hr STD. AIR
(BAROMETRIC DAMPER)
13592 4.98 4.98
16990 7.47 7.47
20388 9.95 9.95
23786 12.44 12.44
50 27184 17.42 17.42
30582 19.91 19.91
33980 24.88 24.88
37378 29.86 29.86
40776 37.33 37.33
135921 4.98 4.98
16990 7.47 7.47
20388 9.95 9.95
23786 12.44 12.44
55 27184 17.42 17.42
30582 19.91 19.91
33980 24.88 24.88
37378 29.86 29.86
40776 37.33 37.33
16990 7.47 7.47
20388 9.95 9.95
23786 12.44 12.44
60
27184 17.42 17.42
30582 19.91 19.91
33980 24.88 24.88
37378 29.86 29.86
40776 37.33 37.33
16990 7.47 7.47
20388 9.95 9.95
23786 12.44 12.44
65
27184 17.42 17.42
30582 19.91 19.91
33980 24.88 24.88
37378 29.86 29.86
40776 37.33 37.33
20388 24.88 7.47
23786 34.84 9.95
27184 44.79 12.44
70
30582 59.72 17.42
33980 74.65 19.91
37378 92.07 24.88
40776 109.49 29.86
44174 131.89 37.33
