YORK INTERNATIONAL 40
Component Static Pressure Drops
TABLE 17 – COMPONENT STATIC PRESSURE DROPS
NOTES: * Includes 2" pleated filters. ** Power exhaust pressure drops are for sizing supply fan.
EVAPORATOR
RETURN AIR OPENING
FILTERS
SIZE
AIR FLOW COILS 50.1 cm 50.1 cm 50.1 cm 50.1 cm
m3/hr STD. AIR WET DRY BOTTOM FRONT SIDE THROWAWAY CLEANABLE PLEATED CARBON
16990 24.83 17.59 10.27 14.79 – 13.14 3.48 10.26 20.98
20388 32.98 23.79 14.79 21.30 – 17.17 5.14 13.69 27.11
23786 41.93 30.71 20.13 28.99 – 21.53 7.16 17.46 33.66
27184 51.63 38.32 26.29 37.87 – 26.19 9.52 21.57 40.61
50
29733 59.36 44.45 31.45 45.30 – 29.87 11.54 24.85 46.06
30582 62.02 46.57 33.28 47.93 – 31.13 12.25 25.98 47.92
33980 73.08 55.46 41.08 59.17 – 36.34 15.35 30.68 55.57
35679 78.85 60.12 45.29 65.23 – 39.04 17.04 33.14 59.51
37378 84.78 64.94 49.71 71.59 – 41.80 18.82 35.67 63.53
40776 97.08 75.01 59.16 85.20 – 47.49 22.68 40.92 71.80
20388 42.85 32.25 14.79 21.30 – 17.17 5.14 13.69 27.11
23786 54.36 41.47 20.13 28.99 – 21.53 7.16 17.46 33.66
27184 66.81 51.56 26.29 37.87 – 26.19 9.52 21.57 40.61
55
30582 80.13 62.47 33.28 47.93 – 31.13 12.25 25.98 47.92
32706 88.89 69.70 38.06 54.81 – 34.36 14.15 28.88 52.66
33980 94.29 74.18 41.08 59.17 – 36.34 15.35 30.68 55.57
37378 109.24 86.66 49.71 71.59 – 41.80 18.82 35.67 63.53
40776 124.94 99.87 59.16 85.20 – 47.49 22.68 40.92 71.80
23786 98.97 61.80 20.13 28.99 – 21.53 7.16 17.46 33.66
27184 119.00 76.36 26.29 37.87 – 26.19 9.52 21.57 40.61
30582 140.02 92.01 33.28 47.93 – 31.13 12.25 25.98 47.92
33980 161.94 108.72 41.08 59.17 – 36.34 15.35 30.68 55.57
60 35679 173.23 117.46 45.29 65.23 – 39.04 17.04 33.14 59.51
37378 184.72 126.44 49.71 71.59 – 41.80 18.82 35.67 63.53
40776 208.30 145.12 59.16 85.20 – 47.49 22.68 40.92 71.80
44174 232.64 164.73 69.43 99.99 – 53.42 26.91 46.44 80.34
45873 245.09 174.87 74.87 107.83 – 56.46 29.18 49.29 84.72
6 23786 92.50 63.35 20.13 28.99 – 21.53 7.16 17.46 33.66
27184 111.93 78.56 26.29 37.87 – 26.19 9.52 21.57 40.61
30582 132.43 94.98 33.28 47.93 – 31.13 12.25 25.98 47.92
33980 153.93 112.56 41.08 59.17 – 36.34 15.35 30.68 55.57
65 35679 165.04 121.76 45.29 65.23 – 39.04 17.04 33.14 59.51
37378 176.38 131.24 49.71 71.59 – 41.80 18.82 35.67 63.53
40776 199.71 151.00 59.16 85.20 – 47.49 22.68 40.92 71.80
44174 223.90 171.79 69.43 99.99 – 53.42 26.91 46.44 80.34
45873 236.29 182.56 74.87 107.83 – 56.46 29.18 49.29 84.72
23786 48.97 30.35 11.09 16.83 29.89 15.51 4.44 12.27 24.60
27184 59.63 37.87 14.48 21.99 39.04 18.87 5.91 15.16 29.68
30582 70.94 46.03 18.33 27.83 49.41 22.44 7.60 18.26 35.02
33980 82.86 54.81 22.62 34.36 61.00 26.19 9.52 21.57 40.61
70 37378 95.36 64.18 27.38 41.57 73.81 30.12 11.68 25.07 46.43
40776 108.41 74.14 32.58 49.47 87.84 34.23 14.07 28.76 52.47
44174 121.99 84.65 38.23 58.06 103.09 38.50 16.70 32.64 58.72
47572 136.08 95.71 44.34 67.34 119.56 42.92 19.56 36.70 65.16
50970 150.65 107.30 50.90 77.30 137.25 47.49 22.68 40.92 71.80
23786 81.48 49.88 11.09 16.83 29.89 15.51 4.44 12.27 24.60
27184 97.69 61.74 14.48 21.99 39.04 18.87 5.91 15.16 29.68
30582 114.63 74.52 18.33 27.83 49.41 22.44 7.60 18.26 35.02
33980 132.27 88.17 22.62 34.36 61.00 26.19 9.52 21.57 40.61
75 37378 150.56 102.67 27.38 41.57 73.81 30.12 11.68 25.07 46.43
40776 169.45 117.97 32.58 49.47 87.84 34.23 14.07 28.76 52.47
44174 188.91 134.06 38.23 58.06 103.09 38.50 16.70 32.64 58.72
47572 208.92 150.90 44.34 67.34 119.56 42.92 19.56 36.70 65.16
50970 229.44 168.48 50.90 77.30 137.25 47.49 22.68 40.92 71.80
