TABLE 18 – GAS HEAT PRESSURE DROPS
SIZE (mbh)
SIZE
AIR FLOW
375
750
1125
m3/hr STD. AIR
16990
29.86
62.21
–
20388
37.33
74.65
–
23786
42.30
87.09
–
27184
49.77
99.54
–
50
29733
54.74
109.49
–
30582
54.74
111.98
–
33980
62.21
124.42
–
37378
67.19
136.86
–
38228
69.68
139.35
–
20388
37.33
74.65
–
23786
42.30
87.09
–
27184
49.77
99.54
–
55
30582
54.74
111.98
–
32706
59.72
119.44
–
33980
62.21
124.42
–
37378
67.19
136.86
–
40776
74.65
149.30
–
23786
42.30
87.09
–
27184
49.77
99.54
–
30582
54.74
111.98
–
33980
62.21
124.42
–
60
35679
64.70
129.40
–
37378
67.19
136.86
–
40776
74.65
149.30
–
44174
79.63
161.75
–
45873
84.61
166.72
–
23786
42.30
87.09
–
27184
49.77
99.54
–
30582
54.74
111.98
–
33980
62.21
124.42
–
65
35679
64.70
129.40
–
37378
67.19
136.86
–
40776
74.65
149.30
–
44174
79.63
161.75
–
45873
84.61
166.72
–
27184
39.81
79.63
119.44
30582
44.79
89.58
134.37
33980
49.77
99.54
149.30
70
37378
54.74
109.49
164.23
40776
59.72
119.44
179.16
44174
64.70
129.40
194.10
45873
67.19
134.37
201.56
SIZE (mbh)
SIZE
AIR FLOW
375
750
1125
m3/hr STD. AIR
27184
39.81
79.63
119.44
30582
44.79
89.58
134.37
33980
49.77
99.54
149.30
75
37378
54.74
109.49
164.23
40776
59.72
119.44
179.16
44174
64.70
129.40
194.10
45873
67.19
134.37
201.56
30582
44.79
89.58
134.37
33980
49.77
99.54
149.30
37378
54.74
109.49
164.23
80
40776
59.72
119.44
179.16
44174
64.70
129.40
194.10
47572
69.68
139.35
209.03
50970
74.65
149.30
223.96
54369
79.63
159.26
236.40
30582
44.79
89.58
134.37
33980
49.77
99.54
149.30
37378
54.74
109.49
164.23
85
40776
59.72
119.44
179.16
44174
64.70
129.40
194.10
47572
69.68
139.35
209.03
50970
74.65
149.30
223.96
54369
79.63
159.26
236.40
33980
44.79
87.09
131.89
37378
47.28
97.05
144.33
40776
52.26
104.51
159.26
44174
57.23
114.47
171.70
90
47572
62.21
124.42
184.14
50970
67.19
131.89
199.07
53519
69.68
139.35
209.03
54369
69.68
141.84
211.51
57767
74.65
149.30
223.96
61165
79.63
159.26
236.40
33980
44.79
87.09
137.61
37378
47.28
97.05
144.33
40776
52.26
104.51
159.26
44174
57.23
114.47
171.70
95
47572
62.21
124.42
184.14
50970
67.19
131.89
199.07
53519
69.68
139.35
209.03
54369
69.68
141.84
211.51
57767
74.65
149.30
223.96
61165
79.63
159.26
236.40
Gas Heat Pressure Drops
