FORM 100.50-EG3 (802)
13 YORK INTERNATIONAL
MODEL SIZE 050 055 060 065 070
Evaporator Coil
Size (Square Meters) 5 5 5 5 5
Number of Rows/Fins per cm 1 1 1 1 1
Tube Diameter (cm) /Surface 5/4 /enhanced 5/4 /enhanced 5/4 /enhanced 5/4 /enhanced 5/4 /enhanced
Condenser Coil (Aluminum Fins)
Size (Square Meters) 11 11 11 11 182
Number of Rows/Fins per cm 1 1 0 0 0
Tube Diameter (cm) 1 1 1 1 1
Condenser Coil (Copper Fins - Opt)
Size (square meters) 11 11 11 11 17
Number of rows/fins per cm 1 1 0 0 0
Tube Diameter 1 1 1 1 1
Condenser Fans
Quantity 4 4 4 4 6
Type Prop. Prop. Prop. Prop. Prop.
Diameter (Meters) 1 1 1 1 1
Power (Hp Each) 2 2 2 2 2
Filters - 5.08cm Throwaway
Quantity 8 / 12 8 / 12 8 / 12 8 / 12 10 / 15
Size (Length x Width) (Meters) .6x.4 / .6x.5 .6x.4 / .6x.5 .6x.4 / .6x.5 .6x.4 / .6x.5 .6x.4 / .6x.5
Total Filter Face Area (Square Meters) 6 6 6 6 7
Filters - 5.08cm Cleanable
Quantity 8 / 12 8 / 12 8 / 12 8 / 12 10 / 15
Size (Length x Width) (Meters) .6x.4 / .6x.5 .6x.4 / .6x.5 .6x.4 / .6x.5 .6x.4 / .6x.5 .6x.4 / .6x.5
Total Filter Face Area (Square Meters) 6 6 6 6 7
Filters - 5.08cm Pleated (30% Efficient)
Quantity 8 / 12 8 / 12 8 / 12 8 / 12 10 / 15
Size (Length x Width) (Meters) .6x.4 / .6x.5 .6x.4 / .6x.5 .6x.4 / .6x.5 .6x.4 / .6x.5 .6x.4 / .6x.5
Total Filter Face Area (Square Meters) 6 6 6 6 7
Filters -30.48cm Rigid 65%, 5.08cm 30% Prefilter
Quantity 1 / 4 / 9 1 / 4 / 9 1 / 4 / 9 1 / 4 / 9 2 / 8 / 9
Size (Length x Width) (Meters) .4x.5 /.6x.4 /.6x.5 .4x.5 /.6x.4 /.6x.5 .4x.5 /.6x.4 /.6x.5 .4x.5 /.6x.4 /.6x.5 .4x.5 /.6x.4 /.6x.5
Total Filter Face Area (Square Meters) 1 1 1 1 1
Filters -30.48cm Rigid 95%, 5.08cm 30% Prefilter
Quantity 1 / 4 / 9 1 / 4 / 9 1 / 4 / 9 1 / 4 / 9 2 / 8 / 9
Size (Length x Width) (Meters) .4x.5 /.6x.4 /.6x.5 .4x.5 /.6x.4 /.6x.5 .4x.5 /.6x.4 /.6x.5 .4x.5 /.6x.4 /.6x.5 .4x.5 /.6x.4 /.6x.5
Total Filter Face Area (Square Meters) 1 1 1 1 1
Filters - 5.08cm Carbon (30% Efficient)
Quantity 1 / 4 / 9 1 / 4 / 9 1 / 4 / 9 1 / 4 / 9 10 / 15
Size (Length x Width) (Meters) .4x.5 /.6x.4 /.6x.5 .4x.5 /.6x.4 /.6x.5 .4x.5 /.6x.4 /.6x.5 .4x.5 /.6x.4 /.6x.5 .6x.4 / .6x.5
Total Filter Face Area (Square Meters) 1 1 1 1 2
Minimum OA Temp. for Mech. Cig. 45 45 45 45 45
TABLE 1 – PHYSICAL DATA – MODELS 50-70 (CONT’D)
