FORM 100.50-EG3 (802)
49 YORK INTERNATIONAL
TABLE 22 – 90 THROUGH 95 TON EXHAUST FAN DATA (CONT’D)
TOTAL STATIC PRESSURE (Pascals of water column)
m3/hr 311 373 435 478
STD. AIR kW RPM kW RPM kW RPM kW RPM
23786 4.3 728 4.8 776 5.3 821 5.8 865
30582 7.8 800 7.8 844 8.3 886 8.9 925
37378 1.9 875 11.7 919 12.5 959 13.3 997
44174 15.6 950 16.7 994 16.7 994 18.7 1072
TOTAL STATIC PRESSURE (Pascals of water column)
m3/hr 62 124 187 249
STD. AIR kW RPM kW RPM kW RPM kW RPM
23786 2.2 474 2.8 555 3.4 621 3.8 677
30582 4.2 563 5.0 633 5.7 696 6.4 751
37378 7.2 660 8.5 716 9.4 773 10.0 826
44174 11.2 761 12.2 807 13.3 855 14.4 904
TABLE 22 – 90 THROUGH 95 TON EXHAUST FAN DATA
TABLE 21 – 70 THROUGH 85 TON EXHAUST FAN DATA (CONT’D)
TOTAL STATIC PRESSURE (Pascals of water column)
m3/hr 311 373 435 478
STD. AIR kW RPM kW RPM kW RPM kW RPM
20388 3.2 694 3.6 744 4.3 792 4.6 839
27184 5.5 762 6.0 807 6.5 850 7.6 890
33980 8.8 837 9.4 881 1.2 921 1.8 959
40776 13.0 912 14.0 956 14.9 997 15.7 1034
TOTAL STATIC PRESSURE (Pascals of water column)
m3/hr 62 124 187 249
STD. AIR kW RPM kW RPM kW RPM kW RPM
20388 1.5 432 2.0 517 2.4 583 2.8 641
27184 3.0 516 3.7 593 4.3 658 4.9 713
33980 5.5 610 6.2 672 7.1 733 7.9 788
40776 9.0 710 9.9 760 1.9 812 12.0 864
TABLE 21 – 70 THROUGH 85 TON EXHAUST FAN DATA
