ZyWALL 10 Internet Security Gateway
NAT
6-11
Table 6-5 Fields in Menu 15.1.1
FIELD
DESCRIPTION
EXAMPLE
Set Name
Enter a name for this set of rules. This is a required
field. Please note that if this field is left blank, the
entire set will be deleted.
NAT_SET
Action
There are four actions. The default is Edit. Edit means
you want to edit a selected rule (see following field).
Insert Before means to insert a rule before the rule
selected. The rules after the selected rule will then be
moved down by one rule. Delete means to delete the
selected rule and then all the rules after the selected
one will be advanced one rule. None disables the
Select Rule item.
Edit
Select Rule
When you choose Edit, Insert Before or Delete in the
previous field the cursor jumps to this field to allow you
to select the rule to apply the action in question.
1
You must press [ENTER] at the bottom of the screen to save the whole set. You must
do this again if you make any changes to the set – including deleting a rule. No
changes to the set take place until this action is taken.
Be careful when ordering your rules as each rule is executed in turn beginning from
rule 1.
Selecting Edit in the Action field and then selecting a rule brings up the following menu, Menu 15.1.1.1
-
Address Mapping Rule in which you can edit an individual rule and configure the Type, Local and
Global Start/End IPs.
Figure 6-9 Menu 15.1.1.1 — Editing an Individual Rule in a Set
Menu 15.1.1.1 Address Mapping Rule
Type= One-to-One
Local IP:
Start=
End = N/A
Global IP:
Start=
End = N/A
Press ENTER to Confirm or ESC to Cancel:
Press Space Bar to Toggle.
