ZyWALL 10 Internet Security Gateway
4-6 Remote Node Setup
4.2 Editing TCP/IP Options (with Ethernet Encapsulation)
Move the cursor to the Edit IP field in menu 11.1, then press the [SPACE BAR] to toggle and set the value
to Yes. Press [ENTER]
to open Menu 11.3 - Network Layer Options.
Figure 4-4 Menu 11.3 — Remote Node Network Layer Options
The next table gives you instructions about configuring remote node network layer options.
Table 4-4 Remote Node Network Layer Options Menu Fields
FIELD DESCRIPTION EXAMPLE
IP Address
Assignment If your ISP did not assign you an explicit IP address, select
Dynamic; otherwise select Static and enter the IP address & subnet
mask in the following fields. Dynamic
IP Address If you have a Static IP Assignment, enter the IP address assigned to
you by your ISP.
IP Subnet
Mask If you have a Static IP Assignment, enter the subnet mask assigned
to you.
Gateway IP
Addr If you have a Static IP Assignment, enter the gateway IP address
assigned to you.
Network
Address
Translation Use the [SPACE BAR] to select either Full Feature, None or SUA
Only. See the NAT chapter for a full discussion on this feature. SUA Only
Metric This field is valid only for PPTP/PPPoE encapsulation. The metric
represents the “cost” of transmission for routing purposes. IP routing
uses hop count as the measurement of cost, with a minimum of 1 for
directly connected networks. Enter a number that approximates the
cost for this link. The number need not be precise, but it must be
between 1 and 15. In practice, 2 or 3 is usually a good number. 3
Menu 11.3 - Remote Node Network Layer Options
IP Address Assignment= Dynamic
IP Address= N/A
IP Subnet Mask= N/A
Gateway IP Addr= N/A
Network Address Translation= SUA Only
Metric= N/A
Private= N/A
RIP Direction= None
Version= N/A
Multicast= None
Enter here to CONFIRM or ESC to CANCEL:
Press Space Bar to Toggle
