ZyWALL 10 Internet Security Gateway
11-8 System Maintenance & Information
11.5 Boot Commands
The BootModule AT commands execute from within the router’s bootup software, when debug mode is
selected before the main router firmware (ZyNOS) is started. When you start up your ZyWALL, you are
given a choice to go into debug mode by pressing a key at the prompt shown in the following screen. In
debug mode you have access to a series of boot module commands, for example
ATUR (for uploading
firmware) and ATLC (for uploading the configuration file). These are already discussed in the
Transferring Files chapter.
Figure 11-9 Option to Enter Debug Mode
Enter ATHE to view all available ZyWALL boot module commands as shown in the next screen. ATBAx
allows you to change the console port speed. The x denotes the number preceding the colon to give the
console port speed following the colon in the list of numbers that follows; e.g.,
ATBA3 will give a console
port speed of 9.6 Kbps. ATSE displays the seed that is used to generate a password to turn on the debug
flag in the firmware. The ATSH command shows product related information such as boot module version,
vendor name, product model, RAS code revision, etc. ATGO allows you to continue booting the system.
Most other commands aid in advanced troubleshooting and should only be used by qualified engineers.
Bootbase Version: V2.02 | 10/11/2000 13:58:03
RAM: Size = 8192 Kbytes
DRAM Post: Testing: 8192K OK
FLASH: Intel 16M
ZyNOS Version: V324\wa0b05 | 3/5/2001 18:00:34
Press any key to enter debug mode within 3 seconds.
