ZyWALL 10 Internet Security Gateway
11-2 System Maintenance & Information
11.2 Call Control Support
The ZyWALL provides two call control functions: budget management and call history. Please note that
this menu is only applicable when Encapsulation is set to PPPoE or PPTP in menu 4 or menu 11.1.
The budget management function allows you to set a limit on the total outgoing call time of the ZyWALL
within certain times. When the total outgoing call time exceeds the limit, the current call will be dropped
and any future outgoing calls will be blocked.
Call history chronicles preceding incoming and outgoing calls.
To access the call control menu, select option 9 in menu 24 to go to Menu 24.9 - System Maintenance -
Call Control, as shown in the next table.
Figure 11-3 Call Control
11.2.1 Budget Management
Menu 24.9.1 shows the budget management statistics for outgoing calls. Enter 1 from Menu 24.9 - System
Maintenance - Call Control to bring up the following menu.
Figure 11-4 Budget Management
Menu 24.9 - System Maintenance - Call Control
1. Budget Management
2. Call History
Enter Menu Selection Number:
Menu 24.9.1 - Budget Management
Remote Node
1. ChangeMe
Connection Time/Total Budget
No Budget
Elapsed Time/Total Period
No Budget
Reset Node (0 to update screen):
