U s i n g t h e C o n t r o l P a n e l

C h a p t e r 3 : T h e C o n t r o l P a n e l 3-17

Printing Test Sheets

Table 3.5 lists the procedures for printing the various test prints.

Table 3.5

Using the Control Panel to print test sheets

Task

Key Press
Sequence

Action/Response

Display Shows

Print the
Configuration
Sheet.

Lists the options you
have installed and the
current settings for
each option in the
Control Panel’s menu
system.

On Line

Takes the printer off-line.

Printing Menu

Menu

Displays the Job Menu.

Job Menu

Menu

Displays the Config Menu.

Config Menu

Menu

Displays the Serial Menu (if present).

Serial Menu

Menu

Displays the Test Menu.

Test Menu

Item

Displays the Config Sheet item.

Config Sheet

Enter

Prints the Configuration Sheet.

Config Sheet

On Line

Returns the printer on-line.

PCL 5e A4/A4

Print the PCL 5e
Font List.

Shows which PCL
fonts are currently
available. The list
includes resident
fonts and downloaded
fonts.

On Line

Takes the printer off-line.

Printing Menu

Menu

Displays the Job Menu.

Job Menu

Menu

Displays the Config Menu.

Config Menu

Menu

Displays the Serial Menu (if present).

Serial Menu

Menu

Displays the Test Menu.

Test Menu

Item

Displays the Config Sheet item.

Config Sheet

Item

Displays the PCL 5e Font List item.

PCL 5e Font List

Enter

Prints the PCL 5e Font List.

PCL 5e Font List

On Line

Returns the printer on-line.

PCL 5e A4/A4

Table 3.5 Page 1 of 3
