U s i n g t h e C o n t r o l P a n e l
C h a p t e r 3 : T h e C o n t r o l P a n e l ❖ 3-15
Change the DTR
Polarity setting.
Controls the
configuration of Data
Terminal Ready
polarity for the
optional serial
interface.
Choices:
High, Low
On Line Takes the printer off-line. Printing Menu
Menu Displays the Job Menu. Job Menu
Menu Displays the Config Menu. Config Menu
Menu Displays the Serial Menu (if present). Serial Menu
Item Displays the Baud Rate item. Baud Rate=X *
Item Displays the Data Bit item. Data Bit=X *
Item Displays the Parity item. Parity=X *
Item Displays the Robust XON item. Robust XON=X *
Item Displays the DTR Polarity item. DTR Polarity=X *
Up or
Down
Changes the polarity setting. DTR Polarity=N
Enter Saves the new value. DTR Polarity=N *
On Line Returns the printer on-line. PCL 5e A4/A4
Change the print
screen setting.
Controls the default
symbol set to allow
80 characters per line
on A4 paper.
Choices:
OFF, 850, 852
On Line Takes printer off-line. Printing Menu
Menu Displays Job Menu. Job Menu
Menu Displays Config Menu. Config Menu
Menu Displays Serial Menu (if present). Serial Menu
Menu Displays Test Menu. Test Menu
Menu Displays Misc Menu. Misc Menu
Item Displays Prt Screen item. Prt Screen=X *
Up or
Down
Changes the screen dump setting. Prt Screen=N
Enter Saves the new value. Prt Screen=N *
On Line Returns printer on-line. PCL 5e A4/A4
Table 3.4 Using the Control Panel to set printer operation (continued)
Task
Key Press
Sequence
†
Action/Response Display Shows
Table 3.4 Page 8 of 9
