P r i n t e r S p e c i f i c a t i o n s
C-4 ❖ D o c u P r i n t 4 5 1 2 / 4 5 1 2 N U s e r G u i d e
Table C.2 Interface Hardware
Parallel Conforms to IEEE STD 1284, February 2, 1993
Connector: Female 36-pin DDK 57LE-40360-730B (D29) or equivalent
AppleTalk Connector: Female 8-pin TCS7189-01-201 or equivalent
Serial Connector: Female 25-pin DDK 17LE-13250-28 (D4CK) or equivalent
Pin Signal Name Source
1 Frame (Ground) ....
2 Transmitted Data Printer
3 Received Data Host
4 Request to Send Printer
6 Data Set Ready Host
7 Ground (Signal) ....
20 Data Terminal Ready Printer
Serial Cable Pin Outs
25 Pin M 25 Pin F 25 Pin M 9 Pin F
Printer Host Printer Host
1
2
3
4
6
7
20
1
3
2
5
7
8
6
2
3
4
6
7
20
2
3
8
4
6
1
20 5
