Chapter 6 Status Screens
P-2602H(W)(L)-DxA User’s Guide
89
6.5 VoIP Statistics
Click Status > VoIP Statistics to access this screen.
Figure 46 VoIP Statistics
Each field is described in the following table.
Interface This field displays either Ethernet (LAN ports) or Wireless (WLAN port).
Status For the LAN ports, this field displays Down (line is down) or Up (line is up or
connected).
For the WLAN port, it displays the transmission rate when WLAN is enabled or
N/A when WLAN is disabled.
TxPkts This field displays the number of packets transmitted on this interface.
RxPkts This field displays the number of packets received on this interface.
Collisions This is the number of collisions on this interfaces.
Poll Interval(s) Type the time interval for the browser to refresh system statistics.
Set Interval Click this to apply the new poll interval you entered in the Poll Interval field
above.
Stop Click this button to halt the refreshing of the system statistics.
Table 20 Packet Statistics (continued)
LABEL DESCRIPTION
Table 21 VoIP Statistics
LABEL DESCRIPTION
SIP Status
Account This column displays each SIP account in the ZyXEL Device.
