Chapter 3 Internet and Wireless Setup Wizard
P-2602H(W)(L)-DxA User’s Guide
68
3.3.1 Manually Assign a WPA key
Choose Manually assign a WPA key in the Wireless LAN setup screen to set up a Pre-
Shared Key.
Figure 27 Manually Assign a WPA key
The following table describes the labels in this screen.
3.3.2 Manually Assign a WEP Key
Choose Manually assign a WEP key to setup WEP Encryption parameters.
Figure 28 Manually Assign a WEP key
Table 12 Manually Assign a WPA key
LABEL DESCRIPTION
Pre-Shared
Key
Type from 8 to 63 case-sensitive ASCII characters. You can set up the most secure
wireless connection by configuring WPA in the wireless LAN screens. You need to
configure an authentication server to do this.
Back Click Back to display the previous screen.
Next Click Next to proceed to the next screen.
Exit Click Exit to close the wizard screen without saving.
