Chapter 18 VPN Screens
P-2602H(W)(L)-DxA User’s Guide
248
End / Subnet Mask When the Remote Address Type field is configured to Single, this field is N/A.
When the Remote Address Type field is configured to Range, enter the end
(static) IP address, in a range of computers on the network behind the remote
IPSec router. When the Remote Address Type field is configured to Subnet,
enter a subnet mask on the network behind the remote IPSec router.
Address
Information
Local ID Type
Select IP to identify this ZyXEL Device by its IP address.
Select DNS to identify this ZyXEL Device by a domain name.
Select E-mail to identify this ZyXEL Device by an e-mail address.
Content
When you select IP in the Local ID Type field, type the IP address of your
computer in the local Content field. The ZyXEL Device automatically uses the IP
address in the My IP Address field (refer to the My IP Address field description)
if you configure the local Content field to 0.0.0.0 or leave it blank.
It is recommended that you type an IP address other than 0.0.0.0 in the local
Content field or use the DNS or E-mail ID type in the following situations.
When there is a NAT router between the two IPSec routers.
When you want the remote IPSec router to be able to distinguish between VPN
connection requests that come in from IPSec routers with dynamic WAN IP
addresses.
When you select DNS or E-mail in the Local ID Type field, type a domain name
or e-mail address by which to identify this ZyXEL Device in the local Content
field. Use up to 31 ASCII characters including spaces, although trailing spaces
are truncated. The domain name or e-mail address is for identification purposes
only and can be any string.
My IP Address
Enter the WAN IP address of your ZyXEL Device. The VPN tunnel has to be
rebuilt if this IP address changes.
The following applies if this field is configured as 0.0.0.0:
The ZyXEL Device uses the current ZyXEL Device WAN IP address (static or
dynamic) to set up the VPN tunnel.
If the WAN connection goes down, the ZyXEL Device uses the dial backup IP
address for the VPN tunnel when using dial backup or the LAN IP address when
using traffic redirect. See
for details on dial backup and
traffic redirect.
Peer ID Type
Select IP to identify the remote IPSec router by its IP address.
Select DNS to identify the remote IPSec router by a domain name.
Select E-mail to identify the remote IPSec router by an e-mail address.
Content
The configuration of the peer content depends on the peer ID type.
For IP, type the IP address of the computer with which you will make the VPN
connection. If you configure this field to 0.0.0.0 or leave it blank, the ZyXEL
Device will use the address in the Secure Gateway Address field (refer to the
Secure Gateway Address field description).
For DNS or E-mail, type a domain name or e-mail address by which to identify
the remote IPSec router. Use up to 31 ASCII characters including spaces,
although trailing spaces are truncated. The domain name or e-mail address is for
identification purposes only and can be any string.
It is recommended that you type an IP address other than 0.0.0.0 or use the DNS
or E-mail ID type in the following situations:
When there is a NAT router between the two IPSec routers.
When you want the ZyXEL Device to distinguish between VPN connection
requests that come in from remote IPSec routers with dynamic WAN IP
addresses.
Table 96 Edit VPN Policies
LABEL
DESCRIPTION
