Printer Tour
Phaser® 8400 Color Printer
1-4
Front View
Side View
Back View
1.
Optional 525-Sheet Tray 4
2.
Optional 525-Sheet Tray 3
3.
Standard 525-Sheet Tray 2
4.
100-Sheet Multi-Purpose Tray 1
5.
Front panel
6.
Exit cover release
7.
Front cover release
8.
Exit cover
9.
Ink loader/Top cover
10.
Legal/A4 output tray extension
11.
Interface cover
12.
Side door
1.
Maintenance kit
2.
Waste tray
3.
Power cord connection
4.
Power switch
5.
Parallel cable connection
6.
USB connection
7.
Configuration card
8.
Ethernet 10/100 Base-T connection
1.
Optional hard drive
2.
Two RAM slots
8400-044
1
2
3
4
7
9
10
8
6
5
12
11
8400-045
1
2
3
4
5
6
7
8
1
8400-046
2
