Connection setup, Connection setup -5 – Xerox Phaser Color Printer 8400 User Manual
Page 101
Connections and IP Address
Phaser® 8400 Color Printer
3-5
Macintosh (OS 9.0.4 and Higher)
A USB-connected printer does not display in the Chooser. Install the printer driver from the
Printer Installer and Utilities CD-ROM. Use the Desktop Printer Utility (version 1.2 or later)
to create a desktop USB printer. The utility is located in the PhaserTools folder which is
created during the software installation. For more information go to
to view Document # 33225.
Macintosh (OS X and Higher)
1.
Install the printer driver from the Printer Installer and Utilities CD-ROM.
2.
Open the Print Center Utility. (On the Macintosh hard drive, open the Applications
folder, then open the Utilities folder.)
3.
Click the Add button.
4.
Select USB from the top drop-down list.
5.
Select the printer in the printers window.
6.
Select Xerox from the list of manufacturers in the drop-down list.
7.
Select the appropriate printer model from the list of available printers.
8.
Click the Add button.
The printer is displayed as an available printer in the Print Center. For more information, go
to view Document # 49355.
Parallel Connection
Use an IEEE 1284 parallel printer cable–maximum length 10 feet (3 meters)–to connect your
computer’s and printer’s parallel ports. Install the printer driver from the Printer Installer and
Utilities CD-ROM. Select the appropriate LPT parallel port.
Connection Setup
Installing the Printer Driver
To download the latest printer drivers, go to
.
Windows 98 or Later and Windows 2000 or Later
Install the printer driver from the Printer Installer and Utilities CD-ROM. The Printer
Installer and Utilities CD-ROM automatically installs and identifies the printer during the
installation process. For
to view
these documents:
■
Windows 98 and Windows Me: Document # 9840
■
Windows 2000, Windows XP, and Windows Server 2003: Document # 36894
■
Windows NT: Document # 11338
