Chapter 7 System Status and Port Statistics
XGS-4526 User’s Guide
75
7.2.1 Status: Port Details
Click a number in the Port column in the Status screen to display individual port
statistics. Use this screen to check status and detailed performance data about an
individual port on the Switch.
Figure 37 Status: Port Details
The following table describes the labels in this screen.
Table 10 Status > Port Details
LABEL DESCRIPTION
Port Info
Port NO. This field displays the port number you are viewing.
Name This field displays the name of the port.
Link This field displays the speed (either 10M for 10Mbps, 100M for 100Mbpsl,
1000M for 1000 Mbps, and 10G for 10 Gbps) and the duplex (F for full
duplex or H for half duplex). It also shows the cable type (Copper or
Fiber).
