Chapter 17 Link Aggregation
XGS-4526 User’s Guide
159
17.3 Link Aggregation Status
Click Advanced Application > Link Aggregation in the navigation panel. The
Link Aggregation Status screen displays by default. See
Section 17.1 on page
157 for more information.
Figure 78 Advanced Application > Link Aggregation Status
The following table describes the labels in this screen.
Table 41 Advanced Application > Link Aggregation Status
LABEL DESCRIPTION
Group ID This field displays the group ID to identify a trunk group, that is, one
logical link containing multiple ports.
Enabled Port These are the ports you have configured in the Link Aggregation screen
to be in the trunk group.
The port number(s) displays only when this trunk group is activated and
there is a port belonging to this group.
Synchronized
Ports These are the ports that are currently transmitting data as one logical link
in this trunk group.
Aggregator
ID Link Aggregator ID consists of the following: system priority, MAC
address, key, port priority and port number. Refer to
Section 17.2.1 on
page 158 for more information on this field.
The ID displays only when there is a port belonging to this trunk group
and LACP is also enabled for this group.
