Chapter 24 Multicast
XGS-4526 User’s Guide
213
24.5 IGMP Filtering Profile
An IGMP filtering profile specifies a range of multicast groups that clients
connected to the Switch are able to join. A profile contains a range of multicast IP
addresses which you want clients to be able to join. Profiles are assigned to ports
(in the Multicast Setting screen). Clients connected to those ports are then able
to join the multicast groups specified in the profile. Each port can be assigned a
single profile. A profile can be assigned to multiple ports.
Cancel Click Cancel to begin configuring this screen afresh.
VLAN Use this section of the screen to add VLANs upon which the Switch is to
perform IGMP snooping.
Name Enter the descriptive name of the VLAN for identification purposes.
VID Enter the ID of a static VLAN; the valid range is between 1 and 4094.
Note: You cannot configure the same VLAN ID as in the MVR
screen.
Add Click Add to insert the entry in the summary table below and save your
changes to the Switch’s run-time memory. The Switch loses these
changes if it is turned off or loses power, so use the Save link on the
top navigation panel to save your changes to the non-volatile memory
when you are done configuring.
Cancel Click Cancel to reset the fields to your previous configuration.
Clear Click this to clear the fields.
Index This is the number of the IGMP snooping VLAN entry in the table.
Name This field displays the descriptive name for this VLAN group.
VID This field displays the ID number of the VLAN group.
Delete Check the rule(s) that you want to remove in the Delete column, then
click the Delete button.
Cancel Click Cancel to clear the Delete check boxes.
Table 63 Advanced Application > Multicast > Multicast Setting > IGMP Snooping
VLAN (continued)
LABEL DESCRIPTION
