Chapter 37 VRRP
XGS-4526 User’s Guide
327
37.3 VRRP Configuration
The following sections describe the different parts of the VRRP Configuration
screen.
37.3.1 IP Interface Setup
Before configuring VRRP, first create an IP interface (or routing domain) in the IP
Setup screen (see the
for more information).
Click IP Application, VRRP and click the Configuration link to display the
VRRP Configuration screen as shown next.
Note: You can only configure VRRP on interfaces with unique VLAN IDs.
VR Status
This field displays the status of the virtual router.
This field is Master indicating that this Switch functions as the master
router.
This field is Backup indicating that this Switch functions as a backup
router.
This field displays Init when this Switch is initiating the VRRP protocol or
when the Uplink Status field displays Dead.
Uplink
Status
This field displays the status of the link between this Switch and the uplink
gateway.
This field is Alive indicating that the link between this Switch and the
uplink gateway is up. Otherwise, this field is Dead.
This field displays Probe when this Switch is check for the link state.
Poll
Interval(s)
The text box displays how often (in seconds) this screen refreshes. You
may change the refresh interval by typing a new number in the text box
and then clicking Set Interval.
Stop
Click Stop to halt system statistic polling.
Table 116 IP Application > VRRP Status (continued)
LABEL
DESCRIPTION
