Chapter 1 Getting to Know Your Switch
XGS-4526 User’s Guide
26
super-fast uplink connection by using the optional 10 Gigabit uplink module on the
Switch.
Figure 1 Bridging Application
1.1.2 High Performance Switching Example
The Switch is ideal for connecting two geographically dispersed networks that
need high bandwidth. In the following example, a company uses the optional 10
Gigabit uplink modules to connect the headquarters to a branch office network.
Within the headquarters network, a company can use trunking to group several
physical ports into one logical higher-capacity link. Trunking can be used if for
example, it is cheaper to use multiple lower-speed links than to under-utilize a
high-speed, but more costly, single-port link.
Figure 2 High Performance Switching
Backbone
RD Sales
HQ
Branch
10 Gbps
Trunk
