Chapter 26 IP Source Guard
XGS-4526 User’s Guide
263
26.7.2 ARP Inspection VLAN Configure
Use this screen to enable ARP inspection on each VLAN and to specify when the
Switch generates log messages for receiving ARP packets from each VLAN. To
open this screen, click Advanced Application > IP Source Guard > ARP
Inspection > Configure > VLAN.
Figure 131 ARP Inspection VLAN Configure
The following table describes the labels in this screen.
Burst interval
(seconds) The burst interval is the length of time over which the rate of ARP
packets is monitored for each port. For example, if the Rate is 15
pps and the burst interval is 1 second, then the Switch accepts a
maximum of 15 ARP packets in every one-second interval. If the
burst interval is 5 seconds, then the Switch accepts a maximum
of 75 ARP packets in every five-second interval.
Enter the length (1-15 seconds) of the burst interval.
Apply Click Apply to save your changes to the Switch’s run-time
memory. The Switch loses these changes if it is turned off or
loses power, so use the Save link on the top navigation panel to
save your changes to the non-volatile memory when you are
done configuring.
Cancel Click this to reset the values in this screen to their last-saved
values.
Table 86 ARP Inspection Port Configure (continued)
LABEL DESCRIPTION
Table 87 ARP Inspection VLAN Configure
LABEL DESCRIPTION
VLAN Use this section to specify the VLANs you want to manage in the
section below.
Start VID Enter the lowest VLAN ID you want to manage in the section
below.
