Chapter 18 Port Authentication
XGS-4526 User’s Guide
169
client connecting to a port on the Switch along with a password configured
specifically for MAC authentication on the Switch.
Figure 84 MAC Authentication Process
18.2 Port Authentication Configuration
To enable port authentication, first activate the port authentication method(s) you
want to use (both on the Switch and the port(s)), then configure the RADIUS
server settings in the AAA > Radius Server Setup screen.
To activate a port authentication method, click Advanced Application > Port
Authentication in the navigation panel. Select a port authentication method in
the screen that appears.
Figure 85 Advanced Application > Port Authentication
New Connection
Authentication Request
Authentication Reply
1
2
3
Session Granted/Denied
