Chapter 18 Port Authentication
XGS-4526 User’s Guide
170
18.2.1 Activate IEEE 802.1x Security
Use this screen to activate IEEE 802.1x security. In the Port Authentication
screen click 802.1x to display the configuration screen as shown.
Figure 86 Advanced Application > Port Authentication > 802.1x
The following table describes the labels in this screen.
Table 44 Advanced Application > Port Authentication > 802.1x
LABEL DESCRIPTION
Active Select this check box to permit 802.1x authentication on the Switch.
Note: You must first enable 802.1x authentication on the Switch
before configuring it on each port.
Port This field displays a port number.
* Settings in this row apply to all ports.
Use this row only if you want to make some settings the same for all
ports. Use this row first to set the common settings and then make
adjustments on a port-by-port basis.
Note: Changes in this row are copied to all the ports as soon as you
make them.
Active Select this checkbox to permit 802.1x authentication on this port. You
must first allow 802.1x authentication on the Switch before configuring it
on each port.
