Text mode
Original mode

The color print head returns to the home position (far left
side of printer) and the WorkCentre cleans the head. After
a few moments, the printer returns to normal print mode.
If the print head does not return to the home position, try
removing and reinstalling the head.

Replacing the automatic
document feed pad

The WorkCentre displays a graphic in the WorkCentre
450c Status window and a message on the control panel
LCD when it’s time to replace the automatic document feed
(ADF) pad. Changes in paper feeding performance also
indicate that you should replace the ADF pad. The ADF pad
allows a single page to be scanned while any remaining
pages stay in the document tray.
To order an ADF pad:

• In the United States, call 1-800-822-2200.
• In Canada, call 1-800-668-0199 (English) or

1-800-668-0133 (French).

1. At the WorkCentre 450c, press the

key.

2. Press

[Setup] and

ENTER
