Page 83
75
Configuration
Control Panel LCD Displays
1/18/06
Z4Mplus/Z6Mplus User Guide
13163L-001 Rev. A
Select Print Mode
Print mode settings tell the printer the method of media delivery that you
wish to use. Make sure that your printer can support the selected option.
Default: TEAR-OFF
Selections: TEAR-OFF, PEEL-OFF, CUTTER, REWIND
To change the value shown:
1.
Press
SELECT
to select the parameter.
2.
Press
PLUS (+)
or
MINUS (-)
to scroll through the options.
3.
Press
SELECT
to accept any changes and deselect the parameter.
Set Media Type
This parameter tells the printer the type of media that you are using (see
for more information). Selecting continuous
media requires that you include a label length instruction in your label
format (
^LLxxxx
if you are using ZPL or ZPL II).
When non-continuous media is selected, the printer feeds media to
calculate label length (the distance between two recognized registration
points of the inter-label gap, webbing, or alignment notch or hole).
Default: NON-CONTINUOUS
Selections: CONTINUOUS, NON-CONTINUOUS
To change the value shown:
1.
Press
SELECT
to select the parameter.
2.
Press
PLUS (+)
or
MINUS (-)
to toggle between the options.
3.
Press
SELECT
to accept any changes and deselect the parameter.
Set the Sensor Type
This parameter tells the printer whether you are using media with a web
(gap/space between labels, notch, or hole) to indicate the separations
between labels or if you are using media with a black mark printed on the
back. If your media does not have black marks for registration on the back,
leave your printer at the default (WEB).
Default: WEB
Selections: WEB, MARK
To change the value shown:
1.
Press
SELECT
to select the parameter.
2.
Press
PLUS (+)
or
MINUS (-)
to toggle between the options.
3.
Press
SELECT
to accept any changes and deselect the parameter.
Table 9 • Printer Parameters (Page 3 of 23)
Parameter
Action/Explanation
PRINT MODE
-TEAR-OFF +
MEDIA TYPE
-NON-CONTINUOUS +
SENSOR TYPE
-WEB +
