Prestige 202H User’s Guide
System Information and Diagnosis 20-1
Chapter 20
System Information and Diagnosis
This chapter covers the information and diagnostic tools in SMT menus 24.1 to 24.4.
20.1 System Status Overview
These tools include updates on system status, port status, log and trace capabilities and upgrades for the
system software. This chapter describes how to use these tools in detail.
Type 24 in the main menu to open Menu 24 – System Maintenance, as shown in the following figure.
Figure 20-1 Menu 24 System Maintenance
20.2 System Status
The first selection, System Status gives you information on the status and statistics of the ports, as shown
next. System Status is a tool that can be used to monitor your Prestige. Specifically, it gives you
information on your G.SHDSL telephone line status, number of packets sent and received.
To get to System Status, type 24 to go to Menu 24 – System Maintenance. From this menu, type 1.
System Status. There are two commands in Menu 24.1 – System Maintenance – Status. Typing 1 resets
the counters, [ESC] takes you back to the previous screen.
The following table describes the fields present in Menu 24.1 – System Maintenance – Status which are
READ-ONLY and meant for diagnostic purposes.
Menu 24 - System Maintenance
1. System Status
2. System Information and Console Port Speed
3. Log and Trace
4. Diagnostic
5. Backup Configuration
6. Restore Configuration
7. Upload Firmware
8. Command Interpreter Mode
9. Call Control
Enter Menu Selection Number:
