Prestige 202H User’s Guide
Dial-in Setup 11-11
Table 11-5 Fields in Menu 15.1.1
FIELD DESRIPTION EXAMPLE
Action The default is Edit. Edit means you want to edit a selected rule (see
following field). Insert Before means to insert a rule before the rule
selected. The rules after the selected rule will then be moved down
by one rule. Delete means to delete the selected rule and then all the
rules after the selected one will be advanced one rule. None disables
the Select Rule item. Edit
Select Rule When you choose Edit, Insert Before or Delete in the previous field
the cursor jumps to this field to allow you to select the rule to apply
the action in question. 1
You must press [ENTER] at the bottom of the screen to save the whole set. You
must do this again if you make any changes to the set – including deleting a rule.
No changes to the set take place until this action is taken.
Selecting Edit in the Action field and then selecting a rule brings up the following menu, Menu 15.1.1.1 -
Address Mapping Rule in which you can edit an individual rule and configure the Type, Local and Global
Start/End IPs.
An End IP address must be numerically greater than its corresponding IP Start
address.
Figure 11-9 Menu 15.1.1.1 Address Mapping Rule
Menu 15.1.1.1 Address Mapping Rule
Type= One-to-One
Local IP:
Start=
End = N/A
Global IP:
Start=
End = N/A
Server Mapping Set= N/A
Press ENTER to Confirm or ESC to Cancel:
Press Space Bar to Toggle.
