Prestige 202H User’s Guide
10-14 Dial-in Setup
Go to Menu 24.8 (Prestige on LAN 2) and type "sys trcl call" to test your connection with callback on CLID.
The Prestige displays all communication traces as shown in the next figure. If CLID authentication fails, this
means that the calling number does not match the Rem CLID number in Menu 11.1.
Figure 10-14 Callback and CLID Connection Test
Copyright (c) 1994 - 2003 ZyXEL Communications Corp.
LAN_2>sys trcl call
Tracelog type 9080 level 1
### Hit any key to terminate
*** INTL CLID check: ch=7743bc reason=-3026
*** INTL chanErr: chp=7743bc state=6 evt=0300
$$$ CALL CONNECT speed<64000> type<2> chan<0>
$$$ LCP opened
$$$ CHAP login to remote OK
$$$ IPCP negotiation started
$$$ IPCP opened
CLID
Authentication
Prestige on LAN 2
callbacks
Connection
