Page 9

O v e r v i e w
C h a p t e r 1 : I n t r o d u c t i o n
❖
1-3
The key printer components are called out in Figure 1.1.
Figure 1.1
Key printer parts
Printer
Components
Power Switch
Font Card Slots
Control Panel Display
Front Output
Middle Paper Slot
Upper Paper Slot
Lower Paper Slot
Manual Feed Slot
(SBF Slot)
Network Ports 1, 2 & 3
Serial Port
Parallel Port
Control Panel Cover
Top Output
Receptacle for
Optional Feeders
Front View
Rear View
Power Inlet
(behind panel)
WUG-CH01 Page 3 Black,Red,Cyan Sunday, January 22, 1995 7:30 PM
