M a i n M e n u S y s t e m
3-12 ❖ 4 5 2 0 / 4 5 2 0 m p U s e r ’ s G u i d e
The Main Menu system is hierarchical, based on a cascading
system of submenus, each containing other submenus or
options designed to configure the printer for your
environment. The Main Menu hierarchy is depicted in
Figure 3.5 (page 3-13) .
In this chapter, factory settings are shown boldfaced and
followed by an asterisk ( * ). See Chapter 1: Introduction
(page 1-4) for a definition of factory setting.
When you change a factory setting or an existing setting to a
new value, the new value becomes the current setting.
On the printer, the current setting always appears first in a list
of values and is followed by an asterisk (*). The other possible
values are located by pressing Up or Down to scroll
through the list.
See “Reset Menu” (page 3-67) for information on how to
revert to factory settings.
Main Menu
System
Note
